Name: Yieh Corp
Brand: Yieh Corp

Product Specification and Size :

Product Specification and Steel Grade (For Reference)

ASTM

JIS

AISI

EN

Mill's Standard

Grade

S30400
S30403
S31603
S43000

S44400

SUS304
-
-
SUS430

SUS444

304
304L
316L
430

444

14301
1.4307
1.4404
1.4016

1.4521

201
202
204Cu3

Other specifications are also available up to request

Available Size

Width	Thickness	Inner Diameter	Available Steel Grade
610~2000 mm	1.2~16.0 mm	610 +0/-5 mm	201, 202, 304, 304L, 316L, 430, 444

Application

Stainless steel has good processing performance and weldability. It is suitable for food processing, storage and transportation, and it can be applied to water heaters, boilers, bathtubs, auto parts (windshield wipers, muffler and molded products), medical equipment, building materials, chemical, food industry, agriculture, marine components, and so on.

Unit Weight Limitation

Unit : ton	3 feet	1M	4 feet	5 feet
300 series	3~17	3~18	3~22	3~23 (≦5.0) / 27 (>5.0)
300 series	-	-	3~22	-
Remark	Both Cut Edge and Mill Edge are available

Dimension and Shape Tolerance (For Reference)

Thickness Tolerance
Thickness	3 feet	1M / 4 feet	5 feet
2.00~2.49 mm	±0.05 mm	±0.06 mm	-
2.50~3.14 mm	±0.06 mm	±0.07 mm	±0.09 mm
2.50~3.14 mm	±0.07 mm	±0.08 mm	±0.10 mm
2.50~3.14 mm	±0.08 mm	±0.09 mm	±0.11 mm

* Aim Tolerance = 1/2 (lower limit + upper limit)

Width Tolerance: Mill Edge: Aim ±10 Cut Edge : Aim -0 / +1

Camber : Max. 5 mm / 2M

Telescope & Protruding Wraps: Mill Edge: 50 mm
Cut Edge: 30 mm

Edge Crack: Mill Edge: Max. 5 mm per side
Cut Edge: Not Allowed

Chemical Composition & Mechanical Property :

Chemical Composition (For Reference)

JIS Specification

Spec.
JIS
G4304
G4305
G4312

Steel Grade	Ni% Max.	Cr% Max.	C% Max.	Si% Max.	Mn% Max.	P% Max.	S% Max.	Mo% Max.	Ti% Max.	Other
SUS304	8.0~10.5	18.0~20.0	0.08	1	2	0.045	0.03	-	-	-
SUS304L	9.0~13.0	18.0~20.0	0.03	1	2	0.045	0.03	-	-	-
SUS316L	12.0~15.0	16.0~18.0	0.03	1	2	0.045	0.03	2.0~3.0	-	-
SUS430	0.60	16.0~18.0	0.12	0.75	1	0.04	0.03	-	-	-

ASTM Specification

Spec.
ASTM
A240

Steel Grade	Ni% Max.	Cr% Max.	C% Max.	Si% Max.	Mn% Max.	P% Max.	S% Max.	Mo% Max.	Ti% Max.	Other
S30400	8.0~10.5	17.5~19.5	0.07	0.75	2	0.045	0.03	-	-	N: 0.1 Max.
S30403	8.0~12.0	17.5~19.5	0.03	0.75	2	0.045	0.03	-	-	N: 0.1 Max.
S31603	10.0~14.0	16.0~18.0	0.03	0.75	2	0.045	0.03	2.0~3.0	-	N: 0.1 Max.
S43000	0.75	16.0~18.0	0.12	1	1	0.04	0.03	-	-	-

Mechanical Property (For Reference)

JIS Specification

Spec.
JIS
G4304
G4305
G4312

Steel Grade	N/mm ₂ MIN. Tensile Stress	N/mm ₂ MIN. Proof Stress	% MIN. Elongation	HRB MAX. Hardness	Bendability: Bending Angle	Bendability: Inside Radius
SUS304	520	205	40	90	No Require	-
SUS304L	480	175	40	90	No Require	-
SUS316L	480	175	40	90	No Require	-
SUS430	420	205	22	88	180°	1.0 time the thickness

ASTM Specification

Spec.
ASTM
A240

Steel Grade	N/mm ₂ MIN. Tensile Stress	N/mm ₂ MIN. Proof Stress	% MIN. Elongation	HBW MAX. Hardness	HRB MAX. Hardness	Bendability: Bending Angle	Bendability: Inside Radius
S30400	515	205	40	92	201	No Require	-
S30403	485	170	40	92	201	No Require	-
S31603	485	170	40	95	217	No Require	-
S43000	450	205	22	89	183	180°	-

Stainless Steel Hot Rolled Coil

Yieh Corp. is a leading stainless steel hot rolled coil supplier, offering the best price and service. We can process orders to any specification, length, and thickness, and then do quality inspection and packaging.
